Name: Gold Plated Tungsten Wire Gold Plating On Tungsten Line Thread String
Brand: SICHUAN WINNER SPECIAL ELECTRONIC MATERIALS CO., LTD.
SKU: TW011
Price: 999 USD
Availability: InStock

Evde > Ürünler > Altınla kaplanmış volfram tel >

Gold Plated Tungsten Wire Gold Plating On Tungsten Line Thread String

gold plated tungsten wire thread

gold plating tungsten line string

tungsten wire with gold plating

Marka adı:

WINNER

Sertifika:

ISO9100

Model numarası:

TW011

Bizimle İletişim

Teklif Et

Ürün Ayrıntıları

Ürün Tipi:

Bağlama teli

Kaplama Kalınlığı:

0.0003mm

Malzeme:

Tungsten

Kaplama:

Altın

Uzun metre:

500/1000

Bağlama yöntemi:

Ultrasonik

Sıcaklık Aralığı:

-40 ° C ila 200 ° C

Yüzey İşlemi:

parlak

İletkenlik:

%98

Paket Boyutu:

100 metre

Bağ gücü:

Yüksek

Paket:

Makara

Vurgulamak:

gold plated tungsten wire thread

gold plating tungsten line string

tungsten wire with gold plating

Ödeme ve Nakliye Şartları

Min sipariş miktarı

1 adet

Fiyat

999

Ambalaj bilgileri

Rulo, nötr paketleme veya OEM logosu ile

Teslim süresi

5-8 iş günü

Ödeme koşulları

L/C, Western Union, T/T

Yetenek temini

Ayda 100000 rulo

İlişkili Ürünler

Uygun Fiyata Yüksek Saflıkta Altın Kaplama Mikron Tungsten Filament Teli Mevcuttur

En İyi Fiyatı Alın

Video

Gold Plated Tungsten Wire Gold Plating On Tungsten Line Thread String

En İyi Fiyatı Alın

Video

Ultra Premium Gold Plated Micron Tungsten Wire For Electronic And Scientific Research

En İyi Fiyatı Alın

High-frequency Customized Diameter Gold Plated Coated Tungsten Spooled Wire

En İyi Fiyatı Alın

Bizimle İletişim

Şimdi iletişime geçin

Ürün Tanımı

Product Description

Gold is the most commonly used thin coating material and does not chemically react under normal conditions. Gold and tungsten have exactly the same density, but their mechanical properties and melting temperatures vary.The most common way to combine the two is to plate gold on the tungsten wire to form a very thin gold-plated layer, which can improve the wettability during welding, prevent chemical corrosion, reduce the secondary emission of electrons, and achieve good performance. electrical contact and conductivity. Gold-plated tungsten wires have the advantages of good tensile strength, strong wear resistance, good plasticity, strong durability, superior oxidation resistance and low production cost.

Product Specifications

Material	Tungsten
Purity	Wu≥ 99.99%
Gold-plated thickness	0.3um
Wire diameter	0.02mm/0.03mm/0.04mm/0.05mm/0.06mm/0.07mm/0.1mm/0.2mm
Length	1000/2000 meter (cut from roll)

Gold plated tungsten wire properties (Theoretical)
Compound Formula	W
Molecular Weight	183.84
Appearance	Metallic wire
Melting Point	3410 °C
Boiling Point	5660 °C
Density	19.3 g/cm3 (25 °C)
Solubility in H2O	N/A
Electrical Resistivity	4.9 μΩ-cm, (20 °C)
Exact Mass	183.951 g/mol
Monoisotopic Mass	183.951 g/mol

Key Features

Shiny golden surface condition - brighter than black or white tungsten wire
Exceptional high temperature resistance and high melting point
Low coefficient of thermal expansion
Superior corrosion resistance compared to ordinary tungsten wire

Applications

Gold-plated tungsten wire serves as an electrode in photocopiers, replacing corrosion-resistant tungsten wire and tungsten aluminum wire. It also functions as an ideal corrosion-resistant electron emission material with applications in high-energy physics, meteorology, and other scientific research fields.

Product Images
